Front Runner 4 Cub Box Drawer — Wide

Short Product Summary

The Front Runner 4 Cub Box Drawer — Wide is a universal drawer system sized for vehicles whose cargo area runs tighter than most. It's a single latched drawer, rated to carry 113kg on its own, with fitting instructions and a flat top deck for extra gear.

Why This Product

A tighter cargo area often means gear gets stacked loose when no vehicle-specific drawer kit suits it. This wide drawer's bearing slides let it pull out almost the full way and a rotating latch keeps it shut when closed, giving a smaller load space a single, secured drawer plus a flat deck on top for whatever else you need to carry.

Key Features

• 113kg per-drawer load rating – the drawer on its own is rated to carry 113kg (250lbs)
• 150kg across the top deck – stack up to 150kg (331lbs) spread over the flat deck surface
• Near-full extension – high-strength bearing slides let the drawer pull out almost the full way
• Rotating latch – keeps the drawer secured shut when closed
• Two equal interior sections – the drawer splits into matching left and right sections either side of a centre rib
• Black powder coat finish – the same finish used on Front Runner's Slimline II Rack

Ideal For

• Vehicles whose cargo area is tighter than most since this wide drawer kit is sized to suit that load space rather than a specific model.
• Anyone needing a solid per-drawer load rating given the 113kg carrying capacity.
• Cub Pack storage users as the drawer is built around Front Runner's stackable Cub Pack containers, sold separately.
• Custom storage builders since the flat top deck is left open for your own combination of boxes and straps.

Local Support from 4Matt Campers

Our Western Cape team can measure this wide drawer kit against your vehicle's cargo area before you order.

Technical Specifications

• Brand: Front Runner
• Part Number: SSAM009
• Consists of: 1 x Drawer unit, Fitting Instructions
• Drawer frame material: Black powder coated mild steel
• Top deck material: Nylon carpet and laminated plywood
• Product dimensions: 653mm (25.7") L x 940mm (37") W x 261mm (10.3") H
• Interior drawer dimensions, full size: 629mm (24.8") L x 890mm (35") W x 45mm (1.8") H, with a 20mm (0.8") H rib down the middle
• Interior drawer dimensions, each section: 629mm (24.8") L x 440mm (17.3") W x 45mm (1.8") H
• Weight: 36.8kg (81.1lbs)
• Load rating: 113kg (250lbs) per drawer; 150kg (331lbs) distributed over the top deck
• Special notes: Rotating latch secures the drawer in place

What's Included

• 1 x Drawer unit
• Fitting instructions

Optional Fitment / Upgrade Notes

This is a universal drawer, so check these points before ordering:

• Measure your vehicle's cargo area against the 653mm x 940mm x 261mm product dimensions, and ask us to confirm fit before ordering.
• There is no vehicle-specific deck completion set or faceplates included, since this is a universal fit.
• Fitting requires a Rivnut tool (we suggest the M6/M8 size), and some vehicles need drilling.
• If there's no rigid surface to mount onto, add a Front Runner Drawer Mount Kit (standard or Tall); Cub Packs are sold separately.

Complete Your Setup

Add Front Runner Stratchits to strap gear to the top deck, browse the full Front Runner range, or see the other drawer systems.

FAQ

How much weight can the drawer carry?
The drawer on its own is rated for 113kg (250lbs), and the top deck for 150kg (331lbs) spread over its surface.

Do Cub Packs come with this drawer?
No. Cub Packs are sold separately from the drawer unit.

Will this fit my vehicle?
It's a universal drawer sized for cargo areas that run tighter than standard. Measure your load area against the product dimensions and ask us to confirm fit before ordering.

What tools do I need to install it?
A Rivnut tool (we suggest the M6/M8 size); drilling may also be required depending on your vehicle.

What warranty does it carry?
Ask us about warranty when you order and we'll give you the details.
