Ultra LED Xtreme Mini LED Spot Light (single)

Short Summary

The Ultra LED Xtreme Mini LED Spot Light is a compact single pod from Ultra LED's Xtreme Series, built around an OSRAM P8 LED chip with Hyper Spot optics. It puts out 4,000 lumens per light and is sold individually, priced per light.

Why This Product

Xtreme pods are sold one at a time, so you can build the lighting layout you want, whether that is a single spot light or a matched pair. Ultra LED notes that a harness is included only when lights are bought in pairs (2, 4, 6 and so on), so singles are best planned together with the wiring.

Key Features

• Hyper Spot optics – a focused spot pattern from an OSRAM P8 LED chip
• 4,000 lumens per light – 30W power draw, as listed by Ultra LED
• Aircraft-grade aluminium housing – paired with a scratch-resistant polycarbonate lens
• Thermal Management System – Ultra LED routes heat from the LED chips through a unique circuit board and deep aluminium cooling fins
• IP67 rating – Ultra LED states the Xtreme Series is protected against dust and sand and tested for at least 30 minutes under 1 metre of water
• 2 Pin Deutsch connection – a sealed connector for the harness

Ideal For

• Owners wanting a compact spot light with a focused pattern
• Builders who want to choose how many lights to fit singles let you run one, two or more
• Buyers adding to an existing Ultra LED setup with a matching extra pod
• 4x4 owners planning a wiring layout before choosing a harness

Local Support from 4Matt Campers

4Matt Campers helps 4x4 owners across the Western Cape and Cape Town plan spot lighting, from the number of pods to the harness and switching that suit them. Tell us what you drive and how many lights you want to run.

Technical Specifications

• Brand: Ultra LED
• Part Number: ULXTRM
• Series: Xtreme Series
• Model: Xtreme Mini
• Light output: 4,000 lumens per light
• Dimensions: 4.76" x 3.6" x 4.95"
• LED chip: OSRAM P8
• Optics: Hyper Spot
• Lens: Scratch-resistant polycarbonate
• Power: 30W
• Connection: 2 Pin Deutsch
• Colour: White, 5400-6000K
• IP rating: IP67
• Sold as: Single light (sold individually)
• Warranty: Ultra LED states a limited 3 years for recreational/off-road use and a limited 1 year for commercial use (original owner, proof of purchase; periods start on the purchase date from a dealer)

What's Included

• 1 x XTREME MINI LED light (sold individually, priced per light)

Optional Fitment / Upgrade Notes

Before you order, check the following:

• Ultra LED lists its dual 2 Pin Deutsch harness (16 and 18 gauge, 60W rated per outlet) as suitable to run 2 x Xtreme 5 or RS3 lights, and its 400W single outlet harness (10 gauge) as suitable to run up to 7 x Xtreme 5 lights.
• Ultra LED's own store notes that single lights ship without a harness and that a harness is included for every pair bought. Ask us what will be supplied with your order.
• Ultra LED lists the Xtreme Mini at 4.76" x 3.6" x 4.95"; check the mounting space before you order.

Complete Your Setup

Browse the full Ultra LED range and all our off-road driving lights & LED light bars. Harnesses, relays and switches are in our 12V electrical accessories.

FAQ

Is the Xtreme Mini sold as a single light?
Yes. Ultra LED sells it per light, so order two for a pair.

Does a wiring harness come with it?
Ultra LED notes that a harness is included only when lights are bought in pairs (2, 4, 6 and so on). Ask us to confirm what ships with your order.

What is the IP rating of the Xtreme Mini?
Ultra LED lists IP67 for the Xtreme Series, tested to work for at least 30 minutes under 1 metre of water.

What warranty does Ultra LED give on its lights?
Ultra LED publishes a limited 3-year warranty for recreational and off-road use, and a limited 1-year warranty for commercial use in agriculture, mining, industrial and public safety. The original owner needs proof of purchase, and warranty periods start on the purchase date from a dealer. Installation errors, misuse and modifications are not covered, so ask us about correct wiring before you install.
