WARN ZEON XD synthetic rope electric winch available from 4Matt Campers in Cape Town

WARN ZEON XD 14-S Winch – 110014

Sold This unit is no longer available, but 4Matt Campers can help you compare current pre-owned stock or find something similar.

This sold listing remains online as a useful reference for buyers researching similar caravans, campers and trailers from 4Matt Campers.

Status Sold

Use this page as a reference, then ask 4Matt Campers to help you find a similar fit.

SKU: Confirm with 4Matt Campers

Aluminium body Off-road ready Code B friendly Options available

This sold listing remains visible for model research and SEO. No quote request or online payment is available for this exact unit.

Overview

Compact, capable and easy to understand.

Short Summary

The WARN ZEON XD 14-S is a premium 14,000lb recovery winch with the highest pulling capacity in its class (supplier-stated), built for heavy rigs and serious recoveries. It includes 3/8” Spydura Pro synthetic rope (80’), a forged aluminium hawse fairlead, a waterproof corded remote, and a HUB wireless receiver for 100’+ wireless control when paired with the WARN HUB app.

Why This Product

When you’re running a heavy vehicle or fully kitted overland rig, recoveries are rarely quick and easy. They’re long pulls, high loads, and unpredictable terrain—often in dust, rain, and mud. The ZEON XD 14-S is designed for those moments: premium waterproof sealing, robust component protection, and a high-capacity pull rating that helps you recover bigger rigs with more control. It’s the kind of winch you fit when failure isn’t an option.

Key Features

  • 14,000lb (6350kg) rated line pull – strong recovery capacity for heavy vehicles and large-frame rigs
  • Premium sealing for harsh conditions – rated IP68 submersion + IP69K high-pressure spray for the entire unit
  • Spydura Pro synthetic rope included3/8” × 80’ (9.52mm × 24.38m) with heat-resistant inner wraps and abrasion sleeve
  • HUB wireless ready – includes HUB receiver for 100’+ wireless control when paired with the WARN HUB app
  • Waterproof corded remote12’ (3.7m) lead for reliable wired control
  • High-performance series-wound motor – WARN high-performance design (supplier-stated)
  • Albright contactor + OE-grade bus bars – built for electrical reliability and efficiency
  • Full metal armour – protects key components from impact and damage
  • Upgraded corrosion resistance – 408-hour salt spray rating (supplier-stated)
  • Premium hawse fairlead – black anodised, forged aluminium; upgraded fairlead made from 6061-T6 billet aluminium (supplier-stated)
  • Industry-leading warranty – limited lifetime mechanical + 7 years electrical

Fitment Note: Requires a compatible bumper or mounting plate for safe mounting. See 4Matt Campers Mounting & Protection options.

Ideal For

  • Clients with heavy SUVs, pickups, and large-frame rigs who need maximum pulling capacity
  • Overland builds carrying additional weight (drawers, bumpers, long-range fuel, rooftop tents, etc.)
  • Western Cape and South Africa routes where mud, sand, and steep terrain demand serious recovery capability
  • Users who want wireless control convenience (HUB receiver + WARN HUB app) plus a waterproof corded remote backup
  • Builds that prefer synthetic rope + hawse fairlead for handling and modern recovery setups

Local Support from 4Matt Campers

4Matt Campers in Cape Town helps clients across the Western Cape plan a complete recovery system: correct winch selection, proper mounting with the right bumper/plate, and a power setup that matches real winching currents. We’ll guide you so your ZEON XD 14-S installation is safe, neat, and ready for serious South African recoveries.

Technical Specifications

  • Brand: WARN
  • Product Category: Premium 4x4 Electric Winch / Vehicle Recovery
  • Rated Line Pull (Single Line): 14,000lb (6350kg)
  • No Load Line Speed: 26.1 ft/min (7.95m/min)
  • Rated Load Line Speed: 2.1 ft/min (0.64m/min)
  • No Load Motor Current: 65A
  • Rated Load Motor Current: 482A, 466A (as supplied)
  • Motor: 12V DC, series wound (WARN high-performance design)
  • Electrical Controls: Contactor
  • Wiring: Automotive OE-grade bus bars
  • Corrosion Resistance: 408-hour salt spray
  • Ingress Protection: IP68 submersion + IP69K spray testing (entire unit)
  • Geartrain: 3-stage planetary
  • Gear Ratio: 213:1
  • Clutch / Free Spooling: Rotating ring gear with stainless steel clutch lever (manual)
  • Brake: Automatic, six-segment mechanical cone
  • Drum Diameter/Length: 3.15” / 9.0” (80mm / 229mm)
  • Rope: 3/8” × 80’ (9.52mm × 24.38m) Spydura Pro synthetic
  • Fairlead: Black anodised, forged aluminium hawse
  • Remote Control: Waterproof corded remote (12’ / 3.7m) + HUB wireless receiver
  • Recommended Battery: 650 CCA minimum for winching
  • Battery Leads: 2 gauge, 72” (1.83m)
  • Finish: Satin-black powder coat
  • Final Assembly: WARN facility, Clackamas, Oregon, USA
  • Warranty: Limited lifetime mechanical + 7 years electrical
  • Weight: 85lb (in box)
  • SKU: 110014

What’s Included

  • WARN ZEON XD 14-S winch (110014)
  • Spydura Pro synthetic rope (3/8” × 80’)
  • Black anodised forged aluminium hawse fairlead
  • Waterproof corded remote (12’ lead)
  • HUB wireless receiver (for use with WARN HUB app)
  • Battery leads (2 gauge, 72”)
  • Mounting hardware: (not specified in supplied text)

Optional Fitment / Upgrade Notes

  • Mounting required: Needs a compatible bumper or mounting plate.
  • Power planning: Rated load motor current is listed as 482A / 466A (as supplied)—your battery, cabling, earth points, isolation, and charging system must be designed for heavy winching.
  • Wireless use: Wireless control requires the WARN HUB app (device compatibility and app availability to be confirmed per phone).
  • Recovery safety: Use rated recovery points and safe winching procedures (gloves, dampers, correct rigging and anchor points).

Need maximum pulling power with premium sealing and modern control options? Enquire now with 4Matt Campers in Cape Town for the WARN ZEON XD 14-S (110014) and we’ll help you plan the right mounting and power setup for your rig.

Complete Your Setup

Browse the full WARN winch range and all our 4x4 winches. A winch needs a compatible winch-ready bull bar and a complete recovery kit.

FAQ

Does the ZEON XD 14-S have wireless control?
Yes—this model includes the HUB receiver for 100’+ wireless control when paired with the WARN HUB app, and it also includes a waterproof corded remote.

How waterproof is the ZEON XD range?
The winch is rated for IP68 submersion and IP69K high-pressure spray testing for the entire unit (supplier-stated).

What rope does it include?
It includes 3/8” Spydura Pro synthetic rope in an 80’ length, with heat-resistant inner wraps and an abrasion sleeve.

What battery is recommended?
WARN recommends a minimum 650 CCA battery for winching.
